CDT-Aviation Obstruction Light

  🔶 High Voltage Transmission Line Marking System – Day & Night Obstruction Light with Complete Solar Kit 🔶 We're proud to introduce our complete obstruction lighting solution designed for high-voltage transmission towers. Powered entirely by solar energy, this system ensures uninterrupted visibility day and night — even in remote or off-grid locations. 🌞 Key Highlights : ✅ Solar panel with adjustable tilt – optimized for the latitude of each country ✅ Gel battery autonomy – more than 7 days of night operation , reducing maintenance needs ✅ Intelligent controller – automatic day/night light operation ✅ Battery protection – safeguards against overcharging and deep discharging ✅ All-in-one kit – includes mounting bracket, lightning rod, junction box, battery box, controller, cables, and clamps Perfect for aviation safety compliance and infrastructure resilience. 📩 Contact Us : 🌐 Website: www.cdt-en.com 📧 Email: sophia@chendongtech.com 📱 Phone/WhatsApp: ...

The White LED Medium Intensity Lighting System combines a daytime white LED light and a nighttime white LED light into a single flashhead. Its self-contained power supply, with available GPS sync and day/night sensor, simplifies wiring and accepts external signals if desired. Advanced features include LED modules, cutting-edge optics, individual LED monitoring/bypass, and active lightning protection. The unit also monitors the system and provides a NO or NC alarm contact upon any system failure. Medium intensity obstruction lighting systems are typically used on structures between 150' (45M) and 500' (150M) above ground level to provide aviation safety. Using medium intensity white strobe during the daytime typically eliminates the need to paint the structure with aviation orange and white stripes. Medium intensity obstruction lights are designed for lighting tall structures such as communication, television and radio towers, chimneys, cooling towers, tall buildings, catenary ...

  ICAO Medium + Low Intensity Red Aviation Obstruction Light System(FAA L-810/L-864 ) for telecommunication towers. - For towers below 45 meters high: 1 or 2 red fixed low intensity at the top; - For towers between 45m and 105m high: 1 red flashing medium intensity type B at the top; 2 or 3 red fixed low intensity type B at mid level (not more than 52 meters from top or ground level) If the tower is higher than 105 meters, additional levels of red medium intensity and low intensity lights should be added alternatively; Available with built-in photocell, external photocell, control box, GPS sync, NVG-compliant infrared (850nm), alarm through built-in dry contacts in OB lights or through dry contacts in the control box; power supply available in DC, AC, and self-contained solar configurations. Website: http://www.cdt-en.com/ Email: sophia@chendongtech.com Phone/WhatsApp:+86-13929493960

Obstruction lights for catenary structures—DC obstruction lights with solar power stations must ensure the marking of high-voltage transmission lines. The size of the battery and solar panel depends on latitude and longitude. Based on the NASA sunshine database, we design and size our 12Vdc or 48Vdc solar kits optimally and with gel batteries best suited to local temperatures. - If markers are installed on the cables, the towers supporting the cables should follow the same requirement for towers as per ICAO annex 14 chapter 6 (see this link obstruction-lights-on-tower) - If it is not possible to install markers on the cables, 3 levels of high intensity type B (or medium intensity in some cases) shall be installed. Consult us for more information: Website: http://www.cdt-en.com/ Email: sophia@chendongtech.com Phone/WhatsApp:+86-13929493960

Medium intensity obstruction lights, red flashing / steady / Infra-red in night mode, with Integrated GPS based flash synchronisation between lights, mounted as close as possible to the top of the structure and at intermediate levels spaced so far as practicable equally between the top lights and ground level at intervals not exceeding 52 m, and the lighting must be displayed at night and arranged to be visible from all directions. For more details: Website: http://www.cdt-en.com/ Email: sophia@chendongtech.com Phone/WhatsApp:+86-13929493960

Obstruction Lighting system - Medium Intensity LED Obstruction Lights Type A/C 20,000cd flashing white at daylight and 2,000cd steady red at night & Type C 2,000cd fixed red light, and the controller provides the control and monitoring functions for the system. For more details: Website: http://www.cdt-en.com/ Email: sophia@chendongtech.com Phone/WhatsApp:+86-13929493960

Wind Turbine Marking & Lighting - LED Obstruction Lighting For Renewable Energy, utilizing LED technology and a custom-sized solar panel, this solution offers universal fit, a compact, lightweight design, and GPS technology provides synchronized flashing for wind farm applications in the renewable energy industry. And a single module integrated within the LED beacon provides monitoring, alarm and synchronizing functions. For more details: Website: http://www.cdt-en.com/ Email: sophia@chendongtech.com Phone/WhatsApp:+86-13929493960
