CDT-Aviation Obstruction Light

For more details: HUNAN CHENDONG TECH CO., LTD Tel:  +0086-0731-85563265                                    Fax: +0086-0731-85563365 Phone/WhatsApp:  +0086-13929493960                Skype:  sophia.guo88 Email:  sophia@chendongtech.com                         Website:  http://www.cdt-en.com/

  ICAO Certified High Intensity White Flash Obstruction Light for 500KV Transmission Line Project For more details: Website: http://www.cdt-en.com / Email: sophia@chendongtech.com

Dual L-864/L-865 Medium Intensity Obstacle Lights White/Red Flashing Solar Powered LED Obstruction Light Model:CK-13T Operating Voltage:DC48V Power consumption:≤20W Flashing frequency:20～40times/min Light intensity: 20000cd(White)/2000(Red) Life span:＞100,000 hours Emitting color:White/RED Beam angle:360° horizontal,> 3° vertical  Overall size: 1070mm×1000mm×490mm Ingress protection:IP65 Lightning protection level: 15KA Light controlled sensitivity: 50Lux Operating temperature:-40℃～55℃ Net weight:53KG Wind load:80m/sec. Battery: 4 units 12V20AH, Colloidal battery Solar Panel: 1067x694x45mm, 62V 120W, Polysilicon Type For more details: HUNAN CHENDONG TECH CO., LTD Tel:  +0086-0731-85563265                                    Fax: +0086-0731-85563365 Phone/WhatsApp:  +0086-13929493960                Skype:  sophia.guo88 Email:  sophia@chendongtech.com                         Website:  http://www.cdt-en.com/

Overhead Wire Marker Fiberglass Aircraft Warning Sphere Day Marking  Aerial Marker Balls for High Voltage Power Lines  Warning sphere is used for warning aircraft pilots in daytime and nighttime, which is compliant with International Civil Aviation Organization (ICAO) recommendations annex 14 chapter 6. It can be used in overhead cable, guyed wire, especially in extra high voltage power transmission line, cross river power transmission line, cross road, bridge power transmission line and so on. It is made of high-grade polyethylene with the color of red, orange, white. Different colors' warning sphere should be displayed alternately. If there are many lines, warning sphere should be displayed on the highest line. It can resistant to corrosion, rust, water, dust, high temperature, can be used for long time. For more details: HUNAN CHENDONG TECH CO., LTD Tel:  +0086-0731-85563265                                    Fax: +0086-0731-85563365 Phone/WhatsApp:  +0086-13929493960

Medium Intensity LED Flashing Red Obstruction Light - FAA L-864 (Medium Intensity LED Flashing Red Obstruction Light 110-240VAC,12-48VDC with GPS Sync)   Model:CK-15 Operating Voltage:AC110-240V Power consumption:≤8W Flashing frequency:20～60times/min Light intensity:2000cd（±25%） Life span:＞100,000 hours Emitting color:RED Beam angle:360° horizontal,> 3° vertical Method of synchronization:GPS Overall size(mm):∅210mm×140mm Installation size(mm):126mm×126mm×4-M10 Ingress protection:IP65 Lightning protection level:10KA Operating temperature:-40℃～55℃ Net weight:2.1KG Wind load:80m/sec. For more details: HUNAN CHENDONG TECH CO., LTD Tel:  +0086-0731-85563265                                    Fax: +0086-0731-85563365 Phone/WhatsApp:  +0086-13929493960                Skype:  sophia.guo88 Email:  sophia@chendongtech.com                         Website:  http://www.cdt-en.com/

L-865 Medium Intensity White LED Flashing Obstruction Beacon Model:CM-15 Operating Voltage:AC110-240V Power consumption:≤20W Flashing frequency:20～60times/min Light intensity:2000-20000cd（±25%） Life span:＞100,000 hours Emitting color:White Beam angle:360° horizontal,>3° vertical Method of synchronization:GPS Overall size(mm):∅268mm×206mm Installation size(mm):166mm×166mm×4-M10 Ingress protection:IP65 Lightning protection level:10KA Optical Sensitivity:100Lux Operating temperature:-40℃～55℃ Net weight:6.1KG Wind load:80m/sec. For more details: Email:  sophia@chendongtech.com   Phone/WhatsApp:  +0086-13929493960

L-801A L-802A White/Green LED Aerodrome Beacon/Aeronautical Beacon, LED Airport Rotating Beacon Model No.:CM-HT12-XZ-4 Input Power:220VAC(other available) Power Consumption:White-150W*2；Green-30W*2 Light Source:LED                                                                    Flashing Frequency: 12rpm, 24 flashes/minute Light Intensity: 25000-50000cd Emitting Color: Green/White Ingress Protection:IP65 Life span:100,000 hours                                                   Altitude:≤2500m Operating temperature:-40℃～55℃ Wind Load: 80m/s Net Weight: 85kg Overall Size: 630x485x1030mm Installation Size: 428x220xM10 For more details: Email:  sophia@chendongtech.com      Phone/WhatsApp:  +0086-13929493960

L-864 Flashing Red Beacon Obstruction Light Medium Intensity LED Obstacle Light, red and infrared omnidirectional medium intensity aviation obstruction light. For more details: HUNAN CHENDONG TECH CO., LTD Tel:  +0086-0731-85563265                                    Fax: +0086-0731-85563365 Phone/WhatsApp:  +0086-13929493960                Skype:  sophia.guo88 Email:  sophia@chendongtech.com                         Website:  http://www.cdt-en.com/

  L-810 Night Marking Telecommunication Towers Solar Obstruction Light Applications: Obstruction light for a wide variety of cranes used in Harbors, Metallurgies, Towers (Telecom, GSM,Smokestacks, Buildings and any other potentially hazardous obstructions for air traffic with a steady burning red or flash safety light. For more details, please contact: Attn: Sophia Guo T:+86-0731-85563165 85563265  | F: +86-0731-85563365  P: +86-13929493960(Whatsapp)  | Skype:sophia.guo88 W:http://www.cdt-en.com/ | E: sophia@chendongtech.com
